The Dongfeng 20-Cubic-Meter Bulk Feed Truck is engineered for large-scale agricultural and livestock operations, combining robust performance with operational efficiency. Its standout advantages include:
- High-Capacity Design
- •With a 20-cubic-meter volume, it significantly reduces transportation cycles, enabling efficient bulk feed delivery for large farms or distributed distribution networks.
- Powerful and Reliable Drivetrain
- •Equipped with a Dongfeng DFH5180ZSLEX81 engine and a Shaanxi 8-speed gearbox, it delivers strong traction and adaptability to complex road conditions while ensuring fuel economy (24 L/100 km).
- Customizable Unloading System
- •Features 3 hoppers (expandable) and a horizontal conveying distance of 3 meters (customizable), allowing flexible adaptation to different farm layouts and operational requirements.
- High Unloading Efficiency with Minimal Loss
- •Achieves a rated discharge capacity of 6.9 kg/min for rapid operations, while maintaining an ultra-low breakage rate (≤5%) and residual rate (≤0.02%), preserving feed quality and reducing waste.
- Excellent Maneuverability and Reach
- •A long but stable wheelbase (8905 mm) ensures smooth driving, and the screw conveyor rotates up to ±180° with a maximum conveying height of ≥6.5 meters, enabling easy access to elevated silos or confined spaces.
- Regulatory Compliance and Durability
- •Designed with a GVM of 18,000 kg and high-strength 10.00R20 18PR tires, it meets road safety standards while offering long-term durability in demanding environments.
- Cost-Effective Operation
- •Low fuel consumption, minimal feed loss, and reduced manual handling requirements contribute to lower overall operating costs and a higher return on investment.
In summary, the Dongfeng 20-CBM truck is an ideal solution for modern agribusinesses seeking high capacity, operational flexibility, and reliability in bulk feed transportation.
Hubei Gongfu Intelligent Equipment Co., Ltd.
Empowering Industry, Forging the Future
We extend a warm invitation to clients and partners worldwide to connect with us. At Gongfu Intelligent, we blend cutting-edge technology with unwavering reliability to deliver customized solutions that drive your success. Our expert team is dedicated to understanding your needs and providing innovative, efficient, and sustainable equipment tailored to your operations.
Whether you are seeking collaboration, technical support, or customized industrial solutions, we are here to assist. Reach out to us today to discover how our expertise can elevate your business.
Contact Us Now – Let’s build a brighter future together!
Chassis Type：
Dongfeng DFH5180ZSLEX81
Engine Type：
B6.2NS6B210
Overall Dimension：
9000×2550×3850
Gearbox Type：
Shaanxi Gear 8-Speed Gearbox
Gross Vehical Weight：
18000
Tire Size：
10.00R20 18PR
Rated Payload：
8905
Wheelbase：
5000
Curb Weight (kg)：
8900
Number of Hoppers：
3 (Customizable)
Horizontal Conveying Distance (m)：
6.9(Customizable)
Rated Discharge Capacity (kg/min)：
≥650
Maximum Conveying Height (m)：
7.5
Comprehensive Fuel Consumption per 100 km：
24（L/100km)
Maximum Discharge Elevation Angle：
＜60°
Breakage Rate (%)：
≤5
Discharge Screw Conveyor Rotation Angle：
±180°
Residual Rate (%)：
≤0.02
