The Liuqi 40-Cubic-Meter Animal Bulk Feed Truck (model: Liuzhou Chenglong LZ1310H7FCT) is engineered for industrial-scale agricultural logistics, delivering unparalleled capacity, efficiency, and adaptability. Its core advantages include:
- Industry-Leading Capacity
- •With a 40-cubic-meter hopper volume and a rated payload of 16,000 kg, it maximizes transport efficiency for large-scale operations, significantly reducing delivery cycles and operational costs.
- Powerful and Efficient Drivetrain
- •Equipped with a high-performance YCK11460-60 engine and a Shaanxi 12-speed gearbox, it delivers exceptional torque and reliability across diverse terrains while maintaining optimized fuel efficiency (32 L/100 km).
- Fully Customizable Unloading System
- •Features 4 hoppers (customizable) and an 8.5-meter horizontal conveying distance (expandable), enabling tailored solutions for complex farm layouts and varying operational demands.
- High-Speed Unloading with Near-Zero Waste
- •Achieves a rapid discharge rate of ≥650 kg/min, drastically reducing unloading time. Coupled with an ultra-low breakage rate (≤5%) and residual rate (≤0.02%), it ensures minimal feed loss and prevents cross-contamination.
- Extended Reach and Precision Placement
- •Offers a maximum conveying height of 9 meters and ±180° screw rotation, allowing effortless feed delivery into elevated silos or confined spaces with pinpoint accuracy.
- Regulatory Compliance and Robust Build
- •Built on a certified Liuzhou Chenglong LZ1310H7FCT chassis with 11.00R20 18PR tires and a gross vehicle weight (GVW) of 31,000 kg, it meets stringent safety standards while ensuring durability in the most demanding environments.
- Cost-Effective Operations
- •Combines high fuel efficiency, minimal feed waste, and reduced labor dependency to deliver superior operational economics and a rapid return on investment for large-scale agribusinesses.
Ideal for global industrial farms and distributors, this truck redefines bulk feed transportation by merging massive capacity, cutting-edge engineering, and unmatched flexibility.
Hubei Gongfu Intelligent Equipment Co., Ltd.
Empowering Industry, Forging the Future
We extend a warm invitation to clients and partners worldwide to connect with us. At Gongfu Intelligent, we blend cutting-edge technology with unwavering reliability to deliver customized solutions that drive your success. Our expert team is dedicated to understanding your needs and providing innovative, efficient, and sustainable equipment tailored to your operations.
Whether you are seeking collaboration, technical support, or customized industrial solutions, we are here to assist. Reach out to us today to discover how our expertise can elevate your business.
Contact Us Now – Let’s build a brighter future together!
Chassis Type：
Liuzhou Chenglong LZ1310H7FCT
Engine Type：
YCK11460-60
Overall Dimension：
12000×2550×3995
Gearbox Type：
Shaanxi Gear 12-Speed Gearbox
Gross Vehical Weight：
31000
Tire Size：
11.00R20 18PR
Rated Payload：
16000
Wheelbase：
2050+4400+1350
Curb Weight (kg)：
15220
Number of Hoppers：
4 (Customizable)
Horizontal Conveying Distance (m)：
8.5(Customizable)
Rated Discharge Capacity (kg/min)：
≥650
Maximum Conveying Height (m)：
9
Comprehensive Fuel Consumption per 100 km：
32（L/100km)
Maximum Discharge Elevation Angle：
＜60°
Breakage Rate (%)：
≤5
Discharge Screw Conveyor Rotation Angle：
±180°
Residual Rate (%)：
≤0.02
